Dual Energy Powerful X Ray Inspection System Baggage Scanner 0.22m/s Conveyor Speed

Dual-energy Powerful X-Ray Inspection System Baggage Scanner with XP System

X Ray Baggage Scanner Description:

Designed for screening oversized luggage, large parcels, and small cargo at airports,

custom facilities, and high security checkpoints. To optimise checkpoint performance,

it is equipped with a powerful generator that produces crisp, high-resolution images that enable

detailed inspections of complex bags and tightly packed crates.

SA6040 allows operators to recognize objects, identify materials,

and isolate threats with better speed and accuracy.

X Ray Baggage Scanner Image System :

1. Image Enhancement: 1-64times enlargement continuity, Color/BW, negative, high/low

penetration, organic /inorganic Stripping, general enhancement, and pseudo color, etc.
2. Image Recall: All preceding images recallable, retrieva
3. High Density Region Alarm: Impenetrable region alarm and highlight,
for possible concealing of threats and contrabands
4. Threat Image Projection: Inserting fictional, but realistic images of threat items into
baggage during screening operation, for maintenance of vigilance, as well as training and
assessment of image identification capability
5. Image Archive: Up to 100,000 images stored automatically, enable transferring to USB disk, and
converting to JPG, BMP and other general formats

6. Images process: 24bit real time processing, 4colors analysis, Images displayed marked date and

ID NO, Count the number of bags, Memory gray level: 65536

X Ray Baggage Scanner Operating Environment​:

Operating temperature: 0℃-40℃
Operating Humidity: 10%-95% (non-condensing)
Storage Temperature: -20℃to 60℃
Storage Humidity: 5%-95% (non-condensing)
Operation Power: 220VAC (±10%) 50±3Hz (Optional: 100VAC,110VAC,120VAC,200VAC)
Power Consumption: 1.0KW (max), 0.7KW (working)

X Ray Baggage Scanner Technical Parameter:

X Ray Baggage Scanner other Specifications:

Noise: <58db

Anode Voltage: 140kv

Anode power: 0.3mA

Generate angle: 80 degree upward

Generate direct: from bottom to top

Cooling / Duty Cycle: Oil Cooling /100%

Extension Rollers: customize size length

Support card reader operator access

CD DVR/RW unit: Optional

Console optional: 17 inch one or two monitor

Industrial Metal Detector Conveyor Product Pictures:

airport x ray machines

cargo security scanning machine

Dual Energy Powerful X Ray Inspection System Baggage Scanner 0.22m/s Conveyor Speed Images
